Extendable corner support WINTERHOFF ADS460 V stabilizer for trailers 450kg 450mm
Extendable corner support WINTERHOFF ADS 460 V stabilizer for trailers 450kg 450mm
The ADS 460 V extendable corner support with a foldable foot from WINTERHOFF is a solid and reliable stabilizing element that provides reliable support for the trailer when parked.
The locating connectors on the chassis allow for quick and easy installation of WINTERHOFF extendable supports . One side of the support is inserted into the connector, while the other is secured to the caravan floor with screws. For maximum stability, the extendable supports should be mounted as far back and outside the caravan as possible , preferably directly to the frame. The greatest stability of the entire structure is achieved by using four supports set at an angle of approximately 30-45° .
Permissible load
The extendable corner support is designed for a load capacity of 450 kg per support , ensuring stable and safe support for the trailer when parked. Using four supports, the maximum permissible load is up to 1,800 kg , ensuring even support for the structure and greater stability for the entire vehicle.
Extension length
The support extension length is 450 mm , allowing for convenient adjustment of the support height to suit various ground conditions and trailer design. The appropriate adjustment range allows for stable trailer positioning during parking, loading, or use.
Crank handle
The corner support is operated using a push-on crank (not included) , which allows for convenient raising and lowering of the support. The mechanism is controlled using a 19mm hex key , ensuring simple and precise height adjustment and stable trailer support when parked. This allows the support to be easily rotated up or down without the need for additional locking or releasing of the mechanism , allowing for quick and convenient preparation of the trailer for parking or driving.
Anti-corrosion protection
The corner support is made of hot-dip galvanized steel, providing high-quality corrosion protection and ensuring long service life even with intensive outdoor use. A thick layer of zinc effectively protects the steel components from moisture, road salt, and changing weather conditions, increasing the durability and resistance of the structure to damage.
Corner supports are a practical piece of trailer equipment used to stabilize the trailer during parking, loading, and unloading . They provide reliable structural support, reduce tilt, and increase safety around the trailer. Fixed supports are most often mounted on the rear or side of the frame and help maintain stability, especially when the trailer is not connected to a vehicle. They are not designed to lift the trailer with a load, but rather to provide stable support. This practical solution is used on cargo trailers, boat trailers, and caravans , improving comfort and safety.
